Output frequency regulation
Overload protection
Outlet quantity / type
INPUT
Nominal Input Voltage(s) Supported
Recommended Electrical Service
Maximum input amps / watts
Input connection type
Voltage compatibility (VAC)
Voltage compatibility (VDC)
BATTERY
Expandable battery runtime
DC system voltage (VDC)
Battery Pack Accessory (optional)
Battery charge
60 Hz (+/- 0.3 Hz)
Includes 15A input breaker dedicated to the charging system and 20A output breaker for AC output loads.
Hardwire
120V AC
DC INPUT: Requires 48VDC input source capable of delivering 56A for the required duration (when used at full
continuous capacity - DC requirements increase during Over-Power and Double-Boost operation).
DC INPUT: Full continuous load - 56A at 48VDC. AC INPUT: 33 amps at 120VAC with full inverter and charger load
(13A max charger-only / combined input load to support charger and AC output is automatically controllable to
66%-33%-0% based on AC output load
DC INPUT: Set of 2 DC bolt-down terminals. AC INPUT: Hardwire via built in junction box with cover plate
120
48
Runtime is expandable with any number of user supplied wet or gel type batteries
48
98-121 sealed lead acid battery (optional)
15A
LEDS ALARMS & SWITCHES
3 position on/off/remote switch enables simple on/off power control plus "auto/remote" setting that enables distant
Switches
Front panel LEDs
PHYSICAL
Shipping Dimensions (HWD/in)
Shipping Dimensions (HWD/cm)
Shipping weight (lbs)
Shipping weight (kg)
Unit Dimensions (HWD/in)
Unit Dimensions (HWD/cm)
Unit weight (lbs)
Unit weight (kg)
Cooling method
on/off control of the inverter system when used in conjunction with optional APSRM4 accessory when used in
inverter mode. In AC uninterruptible power mode, "auto/remote" setting enables automatic transfer from line power
to battery power - to maintain continuous AC power to connected loads.
Set of 6 LEDs offer continuous status information on load percentage (6 levels reported) and battery charge level (7
levels reported). See manual for sequences.
13.5 x 15 x 21.5
34.29 x 38.1 x 54.61
43
19.5
7.25 x 8.5 x 16.75
18.415 x 21.59 x 42.545
38.6
17.5
Multi-speed fan
3 / 5
